Centrifugal Mono block pumps

Single phase mono block pumps

Technical Specifications

TYPE POWER RANGE HEAD RANGE DISCHARGE RANGE PUMP SIZES IN MM
Centrifugal Mono Block 0.5 hp to 2 hp 7 mts to 42 mts 50 lpm to 1000 lpm 25x25 & 32x25 mm
40x40 & 50x40 mm
50x50 & 65x50 mm
75x65 & 75x75 mm

Applications

  • Civil / Domestic / Agriculture / Industrial
  • Pressure boosting for irrigation for washing plants.
  • Irrigation cooling circuits & Gardening.
JAI JANSI JAI JANSI JAI JANSI JAI JANSI JAI JANSI

Three phase mono block pumps

Technical Specifications

TYPE POWER RANGE HEAD RANGE DISCHARGE RANGE PUMP SIZES IN MM
High speed 2880 rpm 3 hp to 15 hp 8 mts to 50 mts 60 lpm to 2500 lpm 50x50 & 65x50 mm
75x65 & 100x75 mm
& 100x100 mm
Slow speed 1440 rpm 3 hp to 15 hp 8 mts to 50 mts 60 lpm to 2500 lpm 50x50 & 65x50 mm
75x65 & 100x75 mm
100x100 & 150x150 mm

Applications

  • Agriculture Irrigation and Drip sprinkler Irrigation
  • Public water supply
  • Industries applications, Water circulation applications.
